Motor |
QSY 155 B EcoDyn |
QSY 155 C EcoDyn |
QSY 155 D EcoDyn |
QSY 155 F EcoDyn |
||||
Rated voltage UN |
417 V/412 V |
420 V/415 V |
412 V/407 V |
399 V/397 V |
||||
Rated power output PN |
3.5 kW/3.1 kW |
5.0 kW/4.5 kW |
5.7 kW/5.1 kW |
6.0 kW/5.4 kW |
||||
Rated speed nN |
3000 rpm (in EcoDyn mode) |
|||||||
Rated torque MN1) |
11.0 Nm/9.9 Nm |
16.0 Nm/14.4 Nm |
18.1 Nm/16.3 Nm |
19.2 Nm/17.3 Nm |
||||
Rated current IN1) |
5.6 A/5.0 A |
8.2 A/7.4 A |
9.1 A/8.2 A |
9.8 A/8.8 A |
||||
Stall torque M01) |
13.0 Nm |
17.7 Nm |
21.6 Nm |
26.1 Nm |
||||
Stall current I01) |
6.5 A |
8.5 A |
10.6 A |
12.8 A |
||||
Max. speed nmax |
4200 rpm (in EcoDyn mode) |
|||||||
Max. torque Mmax2) |
39 Nm |
52 Nm |
64 Nm |
90 Nm |
||||
Max. current Imax2) |
21.2 A |
27.6 A |
35.0 A |
49.5 A |
||||
Mass m |
15.0 kg |
18.0 kg |
17.5 kg |
20.5 kg |
20.0 kg |
23.0 kg |
25.0 kg |
28.0 kg |
Rotor inertia J |
33 kgcm2 |
35 kgcm2 |
43 kgcm2 |
45 kgcm2 |
54 kgcm2 |
56 kgcm2 |
75 kgcm2 |
77 kgcm2 |
Brake Rated voltage UBr Rated current IBr Holding torque MBr |
Without – – – |
With DC 24 V 1.04 A 40 Nm |
Without – – – |
With DC 24 V 1.04 A 40 Nm |
Without – – – |
With DC 24 V 1.04 A 40 Nm |
Without – – – |
With DC 24 V 1.04 A 40 Nm |
ID For motor with ERN 1387 For motor with ECN 1313 For motor with EQN 1325 |
339880-1C 339880-8C 339880-6C |
339880-1D 339880-8D 339880-6D |
365308-1C 365308-8C 365308-6C |
365308-1D 365308-8D 365308-6D |
339881-1C 339881-8C 339881-6C |
339881-1D 339881-8D 339881-6D |
339882-1C 339882-8C 339882-6C |
339882-1D 339882-8D 339882-6D |
1) At 100 K 2) Max. 200 ms Italics: Data for motors with ECN 1313 or EQN 1325 (rated torque reduced by 10 %) |
